K8003
Baby-car parts, Paint drum,Sport appliances, Base of Luggage
×
Property
Test Method
Value
Test Condition
Unit
Melt Flow Index
ASTM D-1238 13.5-18.0 230℃ × 2.16kg g/10 min
IZOD Impact Strength
ASTM D-256 3.0 23℃ 1/8"bar kg-cm/cm
Specific Gravity
ASTM D-792 0.9 23℃ -
Tensile Strength
ASTM D-638 362 23 ℃ kg/cm²
Tensile Elongation at break
ASTM D-638 >200 23℃ %
Flexural Strength
ASTM D-790 15000 23 ℃ kg/cm²
Rockwell Hardness
ASTM D-785 R-101 23 ℃ R-scale
Heat Deflection Temperature
ASTM D-648 115 Unannealed,1/4" bar ℃
Molding Shrinkage
ASTM D-955 1.4 ~
1.8 - %
FDA Compliance
Yes - -
Combustibility
UL-94
File No. E162823
-
Property
Test Method
Value
Test Condition
Unit
IZOD Impact Strength
ISO 180 29 23℃ 1/8"bar kJ/m2
Tensile Strength
ISO 527 35 23 ℃ Mpa
Flexural Modulus
ISO 178 1470 23 ℃ Mpa
Combustibility
UL-94
File No. E162823
-
To print, please click on the attached standard physical properties table.
Hight impact strength, Good Stiffness
Please choose
K8003
Baby-car parts, Paint drum,Sport appliances, Base of Luggage
×
Property
Test Method
Value
Test Condition
Unit
Melt Flow Index
ASTM D-1238 3.6 230℃ × 2.16kg g/10 min
IZOD Impact Strength
ASTM D-256 45 23 ℃,1/8",Notched kg-cm/cm
Specific Gravity
ASTM D-792 0.9 23℃/23℃ -
Tensile Strength
ASTM D-638 260 23 ℃ kg/cm²
Tensile Elongation at break
ASTM D-638 >200 23 ℃,50mm/min %
Flexural Strength
ASTM D-790 11500 23 ℃ kg/cm²
Rockwell Hardness
ASTM D-785 R-83 23 ℃ R-scale
Heat Deflection Temperature
ASTM D-648 115 Unannealed,1.8Mpa 1/4" 厚,120℃/h ℃
Molding Shrinkage
ASTM D-955 1.48 ~
1.8 - %
FDA Compliance
Yes - -
Combustibility
UL-94
File No. E162823
-
Property
Test Method
Value
Test Condition
Unit
IZOD Impact Strength
ISO 180 440 23 ℃,1/8",Notched kJ/m²
Tensile Strength
ISO 527 25 23 ℃ Mpa
Flexural Strength
ISO 178 1127 23 ℃ Mpa
Combustibility
UL-94
File No. E162823
-
To print, please click on the attached standard physical properties table.
Hight impact strength, Good Stiffness
Please choose
K8003
Baby-car parts, Paint drum,Sport appliances, Base of Luggage
×
Property
Test Method
Value
Test Condition
Unit
Melt Flow Index
ASTM D-1238 20-25 230℃ × 2.16kg g/10 min
IZOD Impact Strength
ASTM D-256 4.9(48) 23℃ 1/8"bar kg-cm/cm (J/m)
Specific Gravity
ASTM D-792 0.9 23℃/23℃ -
Tensile Elongation at break
ASTM D-638 >200 23℃ %
Rockwell Hardness
ASTM D-785 R-85 23 ℃ R-scale
Heat Deflection Temperature
ASTM D-648 95 Unannealed,1/4" bar ℃
Molding Shrinkage
FCFC Method 1.4 ~
1.8 23 ℃ %
Tensile Strength at Yield
ASTM D-638 280(27) 23℃ kg/cm2 (Mpa)
Flexural Modulus
ASTM D-790A 11000(1078) 23℃ kgf/cm2
Combustibility
UL-94
File No. E162823
-
Property
Test Method
Value
Test Condition
Unit
Combustibility
UL-94
File No. E162823
-
To print, please click on the attached standard physical properties table.
Hight impact strength, Good Stiffness
Please choose
K8003
Baby-car parts, Paint drum,Sport appliances, Base of Luggage
×
Property
Test Method
Value
Test Condition
Unit
Melt Flow Index
ASTM D-1238 35 230℃ × 2.16kg g/10 min
IZOD Impact Strength
ASTM D-256 5.0(49) 23℃ 1/8"bar kg-cm/cm
Specific Gravity
ASTM D-792 0.9 23℃/23℃ -
Tensile Elongation at break
ASTM D-638 >200 23℃ %
Rockwell Hardness
ASTM D-785 R-85 23 ℃ R-scale
Heat Deflection Temperature
ASTM D-648 95 Unannealed,1/4" bar ℃
Tensile Strength at Yield
ASTM D-638 280(27) 23℃ kg/cm2 (Mpa)
Flexural Modulus
ASTM D-790A 11500 23℃ kgf/cm2
Combustibility
UL-94
File No. E162823
-
Property
Test Method
Value
Test Condition
Unit
Combustibility
UL-94
File No. E162823
-
To print, please click on the attached standard physical properties table.
Hight impact strength, Good Stiffness
Please choose
K8003
Baby-car parts, Paint drum,Sport appliances, Base of Luggage
×
Property
Test Method
Value
Test Condition
Unit
Melt Flow Index
ASTM D-1238 25.0 230℃ × 2.16kg g/10 min
IZOD Impact Strength
ASTM D-256 8.0(78) 23℃ 1/8"bar kg-cm/cm (J/m)
4.1(40) -20℃ 1/8"bar kg-cm/cm (J/m)
Specific Gravity
ASTM D-792 0.9 23℃/23℃ -
Tensile Elongation at break
ASTM D-638 >200 23℃ %
Flexural Strength
ASTM D-790 13121 23 ℃ kg/cm²
Rockwell Hardness
ASTM D-785 R-80 23 ℃ R-scale
Heat Deflection Temperature
ASTM D-648 118 Unannealed,1/4" bar ℃
Molding Shrinkage
FCFC Method 1.4 ~
1.8 23 ℃ %
Tensile Strength at Yield
ASTM D-638 250
(24) 23℃ kg/cm2 (Mpa)
Combustibility
UL-94
File No. E162823
-
Property
Test Method
Value
Test Condition
Unit
Combustibility
UL-94
File No. E162823
-
To print, please click on the attached standard physical properties table.
Hight impact strength, Good Stiffness
Please choose
K8003
Baby-car parts, Paint drum,Sport appliances, Base of Luggage
×
Property
Test Method
Value
Test Condition
Unit
Melt Flow Index
ASTM D-1238 3.0-4.2 230℃ × 2.16kg g/10 min
IZOD Impact Strength
ASTM D-256 45 23℃ 1/8"bar kg-cm/cm
Specific Gravity
ASTM D-792 0.9 23℃/23℃ -
Tensile Strength
ASTM D-638 260 23 ℃ kg/cm²
Tensile Elongation at break
ASTM D-638 >200 23℃ %
Flexural Modulus
ASTM D-790 11500 23 ℃ kg/cm²
Rockwell Hardness
ASTM D-785 R-83 23 ℃ R-scale
Heat Deflection Temperature
ASTM D-648 115 Unannealed,1/4" bar ℃
Molding Shrinkage
ASTM D-955 1.4 ~
1.8 23℃ %
FDA Compliance
YES - -
Combustibility
UL-94
File No. E162823
-
Property
Test Method
Value
Test Condition
Unit
IZOD Impact Strength
ISO 180 440 23 ℃,1/8",Notched kJ/m²
Tensile Strength
ISO 527 25 23 ℃ Mpa
Flexural Modulus
ISO 178 1127 23 ℃ Mpa
Combustibility
UL-94
File No. E162823
-
To print, please click on the attached standard physical properties table.
Hight impact strength, Good Stiffness
Please choose
K8003
Baby-car parts, Paint drum,Sport appliances, Base of Luggage
×
Property
Test Method
Value
Test Condition
Unit
Melt Flow Index
ASTM D-1238 25 230℃ × 2.16kg g/10 min
IZOD Impact Strength
ASTM D-256 2.6 23℃ 1/8"bar kg-cm/cm
Specific Gravity
ASTM D-792 0.9 23℃/23℃ -
Tensile Strength
ASTM D-638 343 23 ℃ kg/cm²
Tensile Elongation at break
ASTM D-638 >200 23℃ %
Flexural Modulus
ASTM D-790 14500 23 ℃ kg/cm²
Rockwell Hardness
ASTM D-785 R-100 23 ℃ R-scale
Heat Deflection Temperature
ASTM D-648 110 Unannealed,1/4" bar ℃
Molding Shrinkage
FCFC Method 1.52 ~
23 ℃ %
Combustibility
UL-94
File No. E162823
-
Property
Test Method
Value
Test Condition
Unit
Combustibility
UL-94
File No. E162823
-
To print, please click on the attached standard physical properties table.
Hight impact strength, Good Stiffness
Please choose
K8003
Baby-car parts, Paint drum,Sport appliances, Base of Luggage
×
Property
Test Method
Value
Test Condition
Unit
Melt Flow Index
ASTM D-1238 31-37 230℃ × 2.16kg g/10 min
IZOD Impact Strength
ASTM D-256 4.0 23℃ 1/8"bar kg-cm/cm
4.0(38) 23℃ 1/8"bar kg-cm/cm (J/m)
Specific Gravity
ASTM D-792 0.9 23℃/23℃ -
Tensile Elongation at break
ASTM D-638 >200 23℃ %
Flexural Modulus
ASTM D-790 18000 23 ℃ kg/cm²
Rockwell Hardness
ASTM D-785 R-105 23 ℃ R-scale
Heat Deflection Temperature
ASTM D-648 125 Unannealed,1/4" bar ℃
Molding Shrinkage
ASTM D-955 1.4 ~
1.8 23℃ %
Tensile Strength at Yield
ASTM D-638 380(37) 23℃ kg/cm2 (Mpa)
Combustibility
UL-94
File No. E162823
-
Property
Test Method
Value
Test Condition
Unit
Combustibility
UL-94
File No. E162823
-
To print, please click on the attached standard physical properties table.
Hight impact strength, Good Stiffness
Please choose
