AC2300
Auto parts, household appliances, 3C electronic products and household goods casings such as wheel covers, handles, Portable storage device
×
Property
Test Method
Value
Test Condition
Unit
Melt Flow Index
ASTM D-1238 7 240℃ × 5kg g/10 min
17 260℃ × 5kg g/10 min
IZOD Impact Strength
ASTM D-256 60 23 ℃ kg-cm/cm
Specific Gravity
ASTM D-792 1.14 23 ℃ g/cm3
Tensile Strength
ASTM D-638 560 23 ℃ kg/cm²
Flexural Strength
ASTM D-790 920 23 ℃ kg/cm²
Flexural Modulus
ASTM D-790 23000 23 ℃ kg/cm²
Rockwell Hardness
ASTM D-785 R-116 23 ℃ R-scale
Heat Deflection Temperature
ASTM D-648 112 Unannealed 6.4mm, 1.8 MPa ℃
Molding Shrinkage
ASTM D-955 0.4 ~
0.6 Flow dir.料流方向 %
Flammability
UL-94 1.5mm HB FILE NO. E162823 -
Combustibility
UL-94
File No. E162823
-
Property
Test Method
Value
Test Condition
Unit
Combustibility
UL-94
File No. E162823
-
To print, please click on the attached standard physical properties table.
Metal plating
Please choose
AC2300
Auto parts, household appliances, 3C electronic products and household goods casings such as wheel covers, handles, Portable storage device
×
Property
Test Method
Value
Test Condition
Unit
Melt Flow Index
ASTM D-1238 37 240℃ × 5kg g/10 min
27 260℃ × 2.16kg g/10 min
IZOD Impact Strength
ASTM D-256 45 23 ℃ kg-cm/cm
15 -30 ℃ kg-cm/cm
Specific Gravity
ASTM D-792 1.18 23 ℃ g/cm3
Tensile Elongation
ASTM D-638 600 23 ℃ kg/cm2
Flexural Strength
ASTM D-790 1000 23 ℃ kg/cm²
Flexural Modulus
ASTM D-790 26000 23 ℃ kg/cm²
Rockwell Hardness
ASTM D-785 R-117 23 ℃ R-scale
Heat Deflection Temperature
ASTM D-648 87 Unannealed 6.4mm, 1.8 MPa ℃
Molding Shrinkage
ASTM D-955 0.4 ~
0.6 Flow dir.料流方向 %
Flammability
UL-94 1.5mm V-0
1.5mm 5V-B FILE NO. E162823 -
Combustibility
UL-94
File No. E162823
-
Property
Test Method
Value
Test Condition
Unit
Combustibility
UL-94
File No. E162823
-
To print, please click on the attached standard physical properties table.
Metal plating
Please choose
AC2300
Auto parts, household appliances, 3C electronic products and household goods casings such as wheel covers, handles, Portable storage device
×
Property
Test Method
Value
Test Condition
Unit
Melt Flow Index
ASTM D-1238 25 240℃ × 5kg g/10 min
IZOD Impact Strength
ASTM D-256 60 23 ℃ kg-cm/cm
-- -30 ℃ kg-cm/cm
Specific Gravity
ASTM D-792 1.18 23 ℃ g/cm3
Tensile Strength
ASTM D-638 600 23 ℃ kg/cm²
Flexural Strength
ASTM D-790 1000 23 ℃ kg/cm²
Flexural Modulus
ASTM D-790 25000 23 ℃ kg/cm²
Rockwell Hardness
ASTM D-785 R-116 23 ℃ R-scale
Heat Deflection Temperature
ASTM D-648 88 Unannealed 6.4mm, 1.8 MPa ℃
Molding Shrinkage
ASTM D-955 0.4 ~
0.6 Flow dir.料流方向 %
Flammability
UL-94 1.5mm V0 FILE NO. E162823 -
Combustibility
UL-94
File No. E162823
-
Property
Test Method
Value
Test Condition
Unit
Combustibility
UL-94
File No. E162823
-
To print, please click on the attached standard physical properties table.
Metal plating
Please choose
AC2300
Auto parts, household appliances, 3C electronic products and household goods casings such as wheel covers, handles, Portable storage device
×
Property
Test Method
Value
Test Condition
Unit
Melt Flow Index
ASTM D-1238 9 240℃ × 5kg g/10 min
21 260℃ × 5kg g/10 min
IZOD Impact Strength
ASTM D-256 50 23 ℃ kg-cm/cm
Specific Gravity
ASTM D-792 1.08 23℃ -
Tensile Strength
ASTM D-638 480 23 ℃ kg/cm²
Flexural Strength
ASTM D-790 840 23 ℃ kg/cm²
Flexural Modulus
ASTM D-790 23000 23 ℃ kg/cm²
Rockwell Hardness
ASTM D-785 R-107 23 ℃ R-scale
Heat Deflection Temperature
ASTM D-648 95 Unannealed 6.4mm, 1.8 MPa ℃
Molding Shrinkage
ASTM D-955 0.4 ~
0.6 - %
Combustibility
UL-94
HB 1.5 mm
File No. E162823
-
Property
Test Method
Value
Test Condition
Unit
Melt Flow Index
ISO 1133 27 260℃ × 2.16kg g/10 min
IZOD Impact Strength
ISO 180 510 23 ℃ 3.2mm J/m
Charpy Impact Strength
ISO 179 35 23 ℃ 4mm kJ/m²
Tensile Strength
ISO 527 47 23 ℃ Mpa
Flexural Strength
ISO 178 82 23 ℃ Mpa
Flexural Modulus
ISO 178 2250 23 ℃ Mpa
Heat Deflection Temperature
ISO 75/A 84 Unannealed 18.6 kg/cm² (1.8MPa)(6.4mm) ℃
Combustibility
UL-94
HB 1.5 mm
File No. E162823
-
To print, please click on the attached standard physical properties table.
Metal plating
Please choose
AC2000
PC/ABS Alloy
General Grade
Auto parts, household appliances, 3C electronic products and houseware shells such as tail lights, cameras, helmets, tablet PC
×
Property
Test Method
Value
Test Condition
Unit
Melt Flow Index
ASTM D-1238 7.0 240℃ × 5kg g/10 min
17 260℃ × 2.16kg g/10 min
IZOD Impact Strength
ASTM D-256 65 23℃, 3.2mm, Notched kg-cm/cm
Specific Gravity
ASTM D-792 1.14 23℃/23℃ -
Tensile Strength
ASTM D-638 600 23 ℃ kg/cm²
Flexural Strength
ASTM D-790 960 23 ℃ kg/cm²
Flexural Modulus
ASTM D-790 24000 23 ℃ kg/cm²
Rockwell Hardness
ASTM D-785 R-116 23 ℃ R-scale
Vicat Softening Point
ASTM D-1525 136 VICAT(10N ℃) ℃
Heat Deflection Temperature
ASTM D-648 112 Unannealed 18.6 kg/cm² (1.8Mpa)(6.4mm) ℃
Molding Shrinkage
ASTM D-955 0.4 ~
0.6 3.2mm %
Flammability
UL-94 1.5-1.65mm HB
All Color FILE NO. E162823 -
Combustibility
UL-94
HB 1.5 ~ 1.65 mm
File No. E162823
-
Property
Test Method
Value
Test Condition
Unit
Melt Flow Index
ISO 1133 7 240℃ × 5kg g/10 min
17 260℃ × 5kg g/10 min
Charpy Impact Strength
ISO 179 55 23 ℃ 4mm kJ/m²
Specific Gravity
ISO 1183 1.14 23℃/23℃ -
Tensile Strength
ISO 527 59 23 ℃ Mpa
Flexural Strength
ISO 178 94 23 ℃ Mpa
Flexural Modulus
ISO 178 2350 23 ℃ Mpa
Rockwell Hardness
ISO 2039-2 R-116 23℃ R-scale
Vicat Softening Point
ISO 306 136 VICAT(10N ℃) ℃
Heat Deflection Temperature
ISO 75/A 0 Unannealed 18.6 kg/cm² (1.8MPa)(6.4mm) ℃
Molding Shrinkage
ISO 2577 0.4 ~
0.6 3.2mm %
Symbol
ISO 1043 >PC+ABS< - -
Combustibility
UL-94
HB 1.5 ~ 1.65 mm
File No. E162823
-
To print, please click on the attached standard physical properties table.
High impact
Please choose
AC2300
PC/ABS Alloy
General Grade
Auto parts, household appliances, 3C electronic products and household goods casings such as wheel covers, handles, Portable storage device
×
Property
Test Method
Value
Test Condition
Unit
Melt Flow Index
ASTM D-1238 9.0 240℃ × 5kg g/10 min
21 260℃ × 2.16kg g/10 min
IZOD Impact Strength
ASTM D-256 55 23℃, 3.2mm, Notched kg-cm/cm
Specific Gravity
ASTM D-792 1.08 23℃/23℃ -
Tensile Strength
ASTM D-638 510 23 ℃ kg/cm²
Flexural Strength
ASTM D-790 880 23 ℃ kg/cm²
Flexural Modulus
ASTM D-790 24000 23 ℃ kg/cm²
Rockwell Hardness
ASTM D-785 R-110 23 ℃ R-scale
Vicat Softening Point
ASTM D-1525 117 VICAT(10N ℃) ℃
Heat Deflection Temperature
ASTM D-648 96 Unannealed 18.6 kg/cm² (1.8Mpa)(6.4mm) ℃
Molding Shrinkage
ASTM D-955 0.4 ~
0.6 3.2mm %
Flammability
UL-94 1.5-1.65mm HB
All Color FILE NO. E162823 -
Combustibility
UL-94
HB 1.5 ~ 1.65 mm
File No. E162823
-
Property
Test Method
Value
Test Condition
Unit
Melt Flow Index
ISO 1133 9 240℃ × 5kg g/10 min
21 260℃ × 5kg g/10 min
IZOD Impact Strength
ISO 180 540 23 ℃ 3.2mm J/m
Charpy Impact Strength
ISO 179 40 23 ℃ 4mm kJ/m²
Specific Gravity
ISO 1183 1.08 23℃/23℃ -
Flexural Strength
ISO 178 86 23 ℃ Mpa
Flexural Modulus
ISO 178 2350 23 ℃ Mpa
Rockwell Hardness
ISO 2039-2 R-110 23℃ R-scale
Vicat Softening Point
ISO 306 117 VICAT(10N ℃) ℃
Heat Deflection Temperature
ISO 75/A 0 Unannealed 18.6 kg/cm² (1.8MPa)(6.4mm) ℃
Molding Shrinkage
ISO 2577 0.4 ~
0.6 3.2mm %
Symbol
ISO 1043 >ABS+PC< - -
Combustibility
UL-94
HB 1.5 ~ 1.65 mm
File No. E162823
-
To print, please click on the attached standard physical properties table.
Metal plating
Please choose
AC2500
PC/ABS Alloy
General Grade
Auto parts, household appliances, 3C electronic products,instrument panel.
grill ,bathroom accessories, electrical control knobs
×
Property
Test Method
Value
Test Condition
Unit
Melt Flow Index
ASTM D-1238 8.0 240℃ × 5kg g/10 min
19 260℃ × 5kg g/10 min
IZOD Impact Strength
ASTM D-256 60 23℃, 3.2mm, Notched kg-cm/cm
Specific Gravity
ASTM D-792 1.12 23℃/23℃ -
Tensile Strength
ASTM D-638 550 23 ℃ kg/cm²
Flexural Strength
ASTM D-790 950 23 ℃ kg/cm²
Flexural Modulus
ASTM D-790 25000 23 ℃ kg/cm²
Rockwell Hardness
ASTM D-785 R-114 23 ℃ R-scale
Vicat Softening Point
ASTM D-1525 130 VICAT(10N ℃) ℃
Heat Deflection Temperature
ASTM D-648 106 Unannealed 18.6 kg/cm² (1.8Mpa)(6.4mm) ℃
Molding Shrinkage
ASTM D-955 0.4 ~
0.6 3.2mm %
Flammability
UL-94 1.5mm HB
3.0mm HB
All Color FILE NO. E162823 -
Combustibility
UL-94
HB 1.5 ~ 3 mm
File No. E162823
-
Property
Test Method
Value
Test Condition
Unit
Melt Flow Index
ISO 1133 8 240℃ × 5kg g/10 min
19 260℃ × 5kg g/10 min
IZOD Impact Strength
ISO 180 585 23 ℃ 3.2mm J/m
Charpy Impact Strength
ISO 179 50 23 ℃ 4mm kJ/m²
Specific Gravity
ISO 1183 1.12 23℃/23℃ -
Tensile Strength
ISO 527 54 23 ℃ Mpa
Flexural Strength
ISO 178 93 23 ℃ Mpa
Flexural Modulus
ISO 178 2450 23 ℃ Mpa
Rockwell Hardness
ISO 2039-2 R-114 23℃ R-scale
Vicat Softening Point
ISO 306 130 VICAT(10N ℃) ℃
Heat Deflection Temperature
ISO 75/A 0 Unannealed 18.6 kg/cm² (1.8MPa)(6.4mm) ℃
Molding Shrinkage
ISO 2577 0.4 ~
0.6 3.2mm %
Symbol
ISO 1043 >PC+ABS< - -
Combustibility
UL-94
HB 1.5 ~ 3 mm
File No. E162823
-
To print, please click on the attached standard physical properties table.
